It also prevents dust particles from entering the processor to help avoid scratches on the film. Light-tight cover The standard light-tight cover allows the operator to perform other tasks while film feeding into the Structurix M ECO film processor is ongoing.The external water and chemical connections assure an efficient and separate drainage of the liquids. Circulating pumps and racks are easy to remove, clean and service. Easy to service Lightweight aluminum side covers enable fast access to the machine.An OK light indicates when the next film can be inserted. The detachable control display provides visual reference of all process parameters (temperature, dryer settings). Film detection with five scanning rollers allow intelligent and economic replenishment depending on the processed film surface. Easy to use Built with an automatic start/stop function.Well-conceived, lightweight construction Constructed of stainless steel, aluminum and PVC to be corrosion resistant strong, lightweight and durable.Compact size Takes up only 0.56 m2 of floor space.situations where space is limited Customized Features.serving as a back-up system to provide flexibility in film solutions and to complement digital solutions.
#GE STRUCTURIX M ECO MANUAL MANUAL#
customers switching from manual processing to an automated system.
on-site testing even with multiple processors which are easy to transport and use. This processor appeals to environmentconscious companies of every size and activity where film image quality is of prime importance. It processes sheet film as well as roll film up to any length. The M ECO processor is versatile, in the laboratory or transportable in a mobile site darkroom. Structurix Mixer (50 Hz) 3 4 5a 5b 6 7 10 Operating diagram: 1 Film feed table 2 Film area scanning 3 Developer tank 4 Intermediate wash area 5 a Fixer tank F1 5 b Fixer tank F2 6 Final wash tank 7 Infrared dryer 8 Film output 9 Film receiving tray 10 Overheating protectors for developer and fixer 9 8Ī Smart Choice for Excellent Film Output The Structurix M ECO is a compact film processor that occupies a minimal amount of space in your darkroom. Water filter with cartridge Peripheral equipment. In addition, during film processing only an ecologically justified volume of water is used and the consumption of electricity is particularly low due to the infrared drying system. Minimal Running Costs The accurate replenishment, as described above, implies low chemical consumption. This unique film area scanning ensures a precise economic, ecologic replenishment operation and reduced replenishment rates. 1 2 Exact Replenishment The surface area of the film is measured accurately on entry by 5 detector rollers. A Recycling-Passport (RP) and Equipment Information Sheet (EIS) are available. Materials or components which can disrupt the recycling process are easy removable. Design for Recycling Extra attention has been given to the selection of the materials in order to improve the recyclability. This system also prevents development faults occuring on the film. Intermediate washing which ensures that there is hardly any carry-over of developer, keeping the fixer bath in optimum condition. Optimal replenishment system as a result of film surface scanning. Infrared drying reducing the amount of heat produced in the darkroom to a minimum. Economical water and electricity consumption. Reduction of fixer replenishment if the Structurix ecoFix is used. Revolutionary cascade fixing system which reduces the amount of silver in the waste water by a factor of 5 to 10. ECOlogical Design The Structurix M ECO lives up to expectations ecologically with: It has been designed for consumers of small and medium quantity of film. The ease of use and the problemfree maintenance make the Structurix M ECO an extremely user-friendly and reliable processor. The secret lies in the double fixing tank, the cascade fixing system - a unique concept in the tabletop processors range. 32 Structurix M ECO Compact and ecological The Structurix M ECO is the most compact processor of the Structurix ECO Film Systems, suited to applications that demand the highest image quality while being ecologically responsible.
